Xirius Alpha-2 USV System
Xirius Alpha-2 USV is an unmanned surface vehicle developed to support modern hydrographic surveying needs. Designed with a focus on stability, accuracy, and flexible sensor integration, it enables safe and efficient data acquisition. A smart solution for precise and controlled water survey operations.
Specification
USV Specification
Material: Kevlar Carbon Fibre Composite
Dimension: 105 x 50 x 40 Cm
Waterproof: IP67
FPV Camera: Yes, HD FPV
Battery: 3 hrs
Echosounder Specification
Type: Single Beam
Operating Frequency: 200 KHz
Beam Angle: 5 or 9 deg
Depth: 0.4 ~ >100 m
Accuracy: 99.46% at full range
Resolution: 0.01 m
Sounding rate: Up to 10 Hz
Submersible: Up to 10 m
GNSS Specification
RTK Positioning: 0.01 m + 1 ppm
Communication: UHF Radio 400-470 MHz, 4G Modern
